Robot operation on various platforms is available by supporting high-capacity additional axes.

- Compatible with various types of robots, including vertically articulated robots
- Drive of large-capacity (~5 kW) additional axes
- Easy slot-level maintenance with modular design
- Category 3 safety design, various safety connections available
- Smoother and more accurate positioning with improved control cycle
- Disassembly, assembly, and moving by checking products moving on the conveyor
- Singularity avoidance: Reduced teaching time of vertically articulated robots for interpolating (straight, arc) in a small space
- Various fieldbus option : CC-Link, PROFIBUS, PROFINET, DeviceNet, Ethernet IP, EtherCAT

Specification
CPU/OS	Motion Control Type	Servo Drive System	Input-Output		Teaching Type	Robot Language	Protection Function	Special Function
CPU/OS	Motion Control Type	Servo Drive System	User	System	Teaching Type	Robot Language	Protection Function	Special Function
X86 Quad Core/RTOS	PTP, CP	8 axes	User In/Out (20 pts/20 pts)	Option In/Out (32 pts/32 pts), Maximum (64 pts/64 pts)	Direct Teaching (Teach Pendant),On-Line Teaching (Uni-Host)	RRL 2.0 (ROBOSTAR Robot Language Version 2)	IPM Error, Over Current, Over Load, Over Speed, Position Error, etc.	3D Palletizing, In-Out Parallel Processing, Real-time Velocity Control
