RA2411 |
Link Arm |
2G |
T : 330°,
Z : 200mm,
L/R : ±433mm,
X : Customer Spec
|
T : 200°/s,
Z : 500mm/s,
L/R : 160°/s,
X : 1000mm/s |
±0.15 mm |
Max. 5Kgf |
Class 10 |
RA3132 |
Link Arm |
3G |
T : 330°,
Z : 2350mm,
L/R : ±925mm,
X : Customer Spec |
T : 148°/s,
Z : 1000mm/s,
L/R : 180°/s,
X : 1800mm/s |
±0.2 mm |
Max. 15Kgf |
Class 10 |
RA4112 |
Link Arm |
4G |
T : 330°,
Z : 2350mm,
L/R : ±925mm,
X : Customer Spec |
T : 148°/s,
Z : 1000mm/s,
L/R : 180°/s,
X : 1800mm/s |
±0.2 mm |
Max. 15Kgf |
Class 10 |
RA4132 |
Slide Arm |
4G |
T : 330°,
Z : 2350mm,
L/R : ±1050mm,
X : Customer Spec |
T axis : 360°/s,
Z : 1250mm/s,
L/R : 1,500mm/s,
X : 1800mm/s |
±0.2 mm |
Max. 15Kgf |
Class 100 |
RA4512 |
Link Arm |
4G |
T : 330°,
Z : 2350mm,
L/R : ±700mm,
X : Customer Spec |
T : 200°/s,
Z : 666mm/s,
L/R : 180°/s,
X : 1800mm/s |
±0.2 mm |
Max. 15Kgf |
Class 10 |
RA4632 |
Slide Arm |
4G |
T : 330°,
Z : 1200mm,
L/R : ±580mm,
X : Customer Spec |
T axis : 202°/s,
Z : 1000mm/s,
L/R : 1,500mm/s,
X : 1800mm/s |
±0.2 mm |
Max. 15Kgf |
Class 100 |
RA5142 |
Slide Arm |
5G |
T : 330°,
Z : 2850mm,
L/R : ±1400mm,
X : Customer Spec |
T : 360°/s,
Z : 1000mm/s,
L/R : 360°/s,
X : 2000mm/s |
±0.1 mm |
Max. 20Kgf |
Class 100 |
RA5512 |
Link Arm |
5G |
T : 330°,
Z : 900mm,
L/R : ±1080mm,
X : Customer Spec |
T : 225°/s,
Z : 1000mm/s,
L/R : 2000mm/s,
X : 1800mm/s |
±0.2 mm |
Max. 20Kgf |
Class 10 |
RA6212 |
Link Arm |
6G |
T : 330°,
Z : 4200mm,
L/R : ±1840mm,
X : Customer Spec |
T : 95°/s,
Z : 1000mm/s,
L/R : 3800mm/s,
X : 2000mm/s |
±0.2 mm |
Max. 25Kgf |
Class 10 |
RA6263 |
Slide Arm, Rotate Hand |
6G |
T : 330°,
Z : 4200mm,
L/R : ±1400mm,
X : Customer Spec |
T : 102°/s,
Z : 1000mm/s,
L/R : 2000mm/s,
X : 1875mm/s |
±0.2 mm |
Max. 25Kgf |
Class 100 |
RA7242 |
Slide Arm |
7G |
T : 330°,
Z : 4200mm,
L/R : 2500mm,
X : Customer Spec |
T : 141°/s,
Z : 1000mm/s,
L/R : 3200mm/s,
X : 2000mm/s |
±0.2 mm |
Max. 30Kgf |
Class 100 |
